Tewaycell 32KWh/28KWh LiFePO4 Battery 51.2V 628Ah/560Ah Mobile ESS With Active Balancer， Fire Extinguisher for Home Energy Storage System
Tewaycell 32KWh/28KWh LiFePO4 Battery 51.2V 628Ah/560Ah Mobile ESS With Active Balancer， Fire Extinguisher for Home Energy Storage System
SKU:
Couldn't load pickup availability
【Communication】: Tewaycell 51.2V lifepo4 battery can communicate with these brands of inverters：Growatt, Goodwe, Deye, SofarSolar, Voltronic, Victron, SRNE, Megarevo, PYLONTECH, Luxpowertek, Sorortec, SMA, GINLONG, MUST, TBB, STUDER, Solis, etc. (Contact us for compatibility with other inverters)
【Energy Expansion】: Tewaycell 32KWh lifepo4 battery supports parallel connection to expand capacity and maximum parallel 15pcs 32kwh lifepo4 battery; Parallel connection requires the same model and brand for optimal performance; It also can be paired with Tewaycell 32kWh built in 10kw or 12kw all-in-one unit, for even greater flexibility and power. If you want to connect products in parallel, it is recommended to order them all at once, because products purchased at different times use different batches of lifepo4 cells. In this case, when connecting them in parallel, the product differentiation will be relatively obvious.
【Usage】: Tewaycell 32KWh lifepo4 mobile energy storage battery features a portable design, perfect for solar home systems, power outages, off-grid living.
【Feature】: Tewaycell 51.2V 628Ah 32KWh lithium battery built-in active balancer module and lifepo4 temperature-sensitive fire extinguisher.
【Packaging】: The wooden box packaging is firm and stable to ensure that the product is not damaged during transportation; And the package usually includes: 1pc 32kwh ESS, 1 pair of positive and negative battery cables, 1pc RS232 cable, manual, if you order more than 1pc of 51.2V 628Ah 32kwh lifepo4 battery, we will provide additional battery-to-battery communication cable.
| Project | |||||
| Model | TW-MB51628- 300A-HWB |
TW-MB51560- 300A-HWB |
TW-MB51628- 200A-HWB |
TW-MB51560- 200A-HWB |
|
| Nominal capacity |
628AH | 560Ah | 628AH | 560AH | |
| Nominal voltage |
51.2V | ||||
| Charging voltage |
56.8-57.6V | ||||
| Operating voltage |
43.2V~58.4V | ||||
| Standard Charging current |
0.2C | ||||
| Standard charging mode |
At a temperature of 25℃,charge to 58.4V with a constant current of 0.2C5A,and then change continuously with a constant voltage of 58.4V until the current is not greater than 0.02C5A. |
||||
| Max. charging current |
300A | 300A | 200A | ||
| Max. discharge current |
300A | 300A | 200A | ||
| Max.output power | 15000W | 15000W | 10000W | ||
| Charging temperature |
0℃to 45℃(32F to113°F)@60±25%relative humidity | ||||
| Discharge temperature |
-20℃to60℃(-4°F to 140°F)@60±25%relative humidity | ||||
| Storage temperature |
-20℃to60℃(-4°F to 140°F)@60±25%relative humidity | ||||
| Line joint | 350A Self-Locking Fitting Quick Release Connector |
350A Self-Locking Fitting Quick Release Connector |
250A Self-Locking Fitting Quick Release Connector |
||
| Net Weight Approx. |
238KG | ||||
| Communication protocol |
RS485、RS232、CAN、WiFi | RS485、RS232、CAN、WiFi | RS485、RS232、CAN | ||
| Suppot inverter brand |
Growatt、Deye、Goodwe、voltronic、Sofar、VICTRON、 Megarevo、SRNE、PYLON、Luxpowertek、Sorotec、SMA、 GINLONG、MUST、TBB、STUDER |
||||
下载文档：
User Manual
